If you’ve been researching solar power — whether it’s for a home in Bournemouth, a shop in Poole, or a commercial solar project in Christchurch — you may have come across the term “120% rule.”
This rule is part of the United States’ National Electrical Code (NEC), not UK legislation, but the underlying idea is worth knowing about. Even here in Dorset, where we follow different electrical regulations, understanding this concept can help you make informed decisions about your solar installation and avoid costly surprises.
In the US, the 120% rule governs how much solar power you can safely feed into your home’s breaker panel (what we call a consumer unit in the UK) without exceeding its design limits.
It’s based on the busbar — the solid metal strip inside your panel that carries electricity to the breakers. The formula looks like this:
Busbar rating: The maximum current the internal connections in your consumer unit can handle.
Main breaker rating: The maximum current your home can draw from the grid.
The “× 1.2” part is where the “120%” comes from — it’s an allowance for solar systems to add some extra capacity without upgrading the panel, as long as it’s within safe limits.
We don’t have the 120% rule written into our standards here. Instead, UK installations must comply with the IET Wiring Regulations (BS 7671) and local Distribution Network Operator (DNO) requirements.
However, the principle behind the 120% rule — making sure your electrical system is not overloaded — still applies. In practice, this means:
Checking your consumer unit’s capacity before installing solar panels.
Ensuring the circuit protection is adequate for both your grid supply and your solar feed-in.
Following guidelines for safe backfeeding and system integration.
For many homes in Dorset, especially older properties, the consumer unit may need upgrading before larger systems like Tesla solar panels or a Qcell battery can be installed.
Let’s imagine you live in Bournemouth with a consumer unit that has a 100A busbar and a 100A main breaker.
Under the US NEC rule:
100A × 1.2 = 120A total allowable current
120A − 100A (main breaker) = 20A available for solar backfeed
That 20A limit might mean you can only install a system of a certain size without changing your consumer unit.
In the UK, your installer won’t calculate it in quite the same way, but they will run similar capacity checks. If you’re in Poole looking to add a commercial solar array, they’ll assess whether your existing setup can safely handle the extra generation — especially if you plan to store excess energy in a battery system.
One of the main reasons to be aware of capacity limits is that they can affect:
The number of panels you can install
The size of your inverter
Whether you can easily add battery storage later (e.g., a Qcell battery)
How much of your roof space can realistically be used
For example, you might want to cover your whole roof with solar panels in Christchurch, but if your consumer unit can’t handle the full capacity, your installer may suggest either limiting the system size or upgrading your electrical infrastructure.
If you find your electrical panel is the bottleneck, there are a few potential solutions your installer might suggest:
Upgrade your consumer unit — Increasing the busbar rating allows for a larger safe load.
Use a smaller main breaker — This can sometimes free up capacity for solar backfeed, but it must be done carefully to avoid restricting your home’s power.
Install a dedicated solar distribution board — Keeps the solar system separate from the main consumer unit.
Consider load-side connections — An alternative wiring approach that may bypass the main breaker limit, if allowed by your DNO.
The Dorset area is seeing a big increase in solar adoption, both for domestic and commercial use. Towns like Bournemouth and Poole have plenty of properties that are ideal for solar, but many also have older electrical systems that may not be ready for a high-capacity installation.
By understanding the principle behind the 120% rule, you can:
Ask better questions when getting quotes from solar companies near me.
Plan for upgrades if you want to future-proof your system.
Avoid disappointment if your installer says your system can’t be as large as you hoped without extra work.
“It applies in the UK just like in the US.” – It doesn’t; we use different regulations, but the safety logic is similar.
“Any installer can work around it.” – Not true; limits exist for safety reasons.
“If my roof can fit the panels, my system can handle them.” – The electrical side can be just as limiting as physical space.
Q: Does this rule apply to Dorset solar panel installations?
A: Not officially, but your installer will follow similar principles to keep your system safe.
Q: What if I’m installing Tesla solar panels and a Qcell battery?
A: Your installer will check your system capacity and may suggest a consumer unit upgrade.
Q: Can I avoid these limits by installing off-grid?
A: Technically yes, but most homes want grid connection for reliability, which means following all safety rules.
The solar 120% rule might be a US regulation, but its concept — making sure you don’t overload your electrical system — is vital everywhere.
If you’re considering solar panels in Bournemouth, Poole, or Christchurch, understanding how system capacity works will help you make better decisions and avoid unexpected upgrade costs. Whether it’s a modest home array or a commercial solar project with battery storage, capacity limits are just as important as panel efficiency or sunlight hours.
By working with a reputable local installer, you can ensure your system is designed not only to generate maximum clean energy but also to work seamlessly — and safely — with your home or business’s electrical system.
